EX-PROOF ELECTRONIC GROUNDING SYSTEM (TEPEX)

Product Code:GGCD-01

GGCD Exproof Electronic Grounding System

Enclosure:Polyester plastic reinforced with glass fiber, color – black.
Cover:with integrated Thermoplastic elastomer gasket, closes with four M6 stainless steel screws.
Active grounding system for static grounding and permanent monitoring.
Two output contacts.

GGCD 01 / K1 1 Pliers
GGCD 01 / K2 2 Pliers

Files

File Name	File Size	Actions
GGCD-01-DATA SHEET	561 KB	Download
GGCD-01-ATEX	3664 KB	Download
GGCD-01-EAC Click to View All EAC Certified Products	2841 KB	Download
GGCD-01-USER'S GUIDE	1381 KB	Download

Description

GAS	II 2G Ex db eb mb [ib] IIC T5 Gb	IP66	Zone 1 - Zone 21 - Zone 2 - Zone 22
DUST	II 2D Ex tb [ib] IIIC T80C Db	24VDC & 230VAC	-20ºC ≤ Ta ≤ +50ºC [ATEX]	-50ºC ≤ Ta ≤ +50ºC [EAC]
