BAK85 series Ex-proof Led Tank lighting fixture (WAROM)
Product Code:BAK85
- BAK85 series Ex-proof LED Tank lighting fixture is aluminum body.
- Color temperature (CCT) cool white: 5700K
- Ground protection M5 (inner and outer ground bolts)
- Terminal 3 x 1.5 ~ 2.5mm2 (TH + N + PE)
- M20x1,5 Inlet hole. (except gland.)
Description
GAS | II 2 G Ex db op is IIC T6 Gb | IP66/IP67 | Zone 1 - Zone 21 - Zone 2 - Zone 22 | |
DUST | II 2 D Ex tb op is IIIC T80°C Db | IP66/IP67 | -40°C ÷ +55°C | TPS 18 ATEX 089761 0007X |
Code No | Lamp Power | Voltage | U.Weight (kg) |
|---|---|---|---|
BAK85-9/277 | 9W | 110~277V AC 50/60Hz | 2,20 |
BAK85-9/36 | 9W | 12~-36V AC | 2,20 |
BAK85-9/48 | 9W | 12~48V AC | 2,20 |
