EX-PROOF POLYAMIDE CABLE GLAND (EATON / CEAG)
Product Code:GHG 960
- GHG 960 1955 R00.. type Ex-proof cable glands are available in stock as metric thread only.
- It is stocked in sizes from M16x1.5 to M63x1.5 mm.
- There is no locking nut on the fittings. In case of need it should also be requested.
Description
GAS | II 2 G Ex eb IIC Gb | IP66 | Zone 1- Zone 21- Zone 2- Zone 22 | |
DUST | II 2 D Ex tb IIIC Db | IP66 | -20°C ÷ +70°C | -40°C ÷ +70°C |
Code No | Thread Size | Clamping Range (mm) |
|---|---|---|
GHG 960 1955 R0022 | M16x1,5 | 5,5-10 |
GHG 960 1955 R0023 | M20x1,5 | 5,5-13 |
GHG 960 1955 R0024 | M25x1,5 | 8,0-17 |
GHG 960 1955 R0025 | M32x1,5 | 12-21 |
GHG 960 1955 R0026 | M40x1,5 | 17-28 |
GHG 960 1955 R0027 | M50x1,5 | 22-35 |
GHG 960 1955 R0028 | M63x1,5 | 27-48 |
