EX-PROOF COMPACT FLUORESCENT FIXTURE

Product Code:FLX

FLX type Tepex brand ex-proof lighting fixtures are aluminum cast housing and electronic ballast.
FLX type fluorescent lamps Led fluorescent light bulbs can be installed.
FLX type ex-proof compact fluorescent fixtures have a small size, providing more economical and easy installation advantage.
FLX type fluorescent fixtures have 2 M20x1.5 inlet holes.
Ex-proof lighting fixture is ceiling type and mounting legs are provided with it.

File Name	File Size	Actions
FLX-DATA SHEET	723 KB	Download
FLX-ATEX	165 KB	Download
FLX-EAC Click to View All EAC Certified Products	1411 KB	Download

GAS	II2G Ex db eb IIC T5/T6 Gb	IP66	Zone 1 - Zone 21 - Zone 2 - Zone 22
DUST	II2D Ex tb IIIC T80°C Db	IP66	-20°C ÷ +50°C (ATEX)	-50°C ÷ +50°C (EAC)

Code No	Lumen lm	Lamp Power	Voltage	A (mm)	B (mm)	C (mm)	U.Weight kg
FLX-218	2x1200	2x18W	100 V ÷ 280 V AC/DC	366	225	174	4,60
FLX-236	2x2900	2x36W	100 V ÷ 280 V AC/DC	555	416	174	5,80
FLX-255	2x4700	2x55W	100 V ÷ 280 V AC/DC	680	542	174	8,00
